Novec 1230/Fluoroketone/F-K-5-1-12 IndusTrial Fire Safety So
Efficiency and Eco-Friendliness Go Hand-in-Hand
Novec 1230/Fluroketone/ FK-5-1-12 is a state-of-the-art, eco-friendly fire extinguishing system is especially designed to safeguard high-value equipment from accidental fires. This system has been successfully implemented and widely accepted to protect large-room fires for:
- Huge data center
- Server room
- UPS room
- Battery room
- Hospitals
- Hotels
- MRI room (Non-Magnetic Cylinder)
NOVEC 1230 in 25 bar, 42 bar and 70 bar UL certified Gas Suppression system contains an environmentally acceptable fire protection fluid that suppresses the fire by removing the heat energy in 10 seconds. Solution comes with UL certified flow calculation report with PESO approved Cylinder & Valve. This NOVEC 1230 fluid is a clean agent for vital facilities and douses the fire by interrupting the combustion process. It extinguishes fire before any substantial fire damage has been done. The NOVEC 1230 Gas Suppression system can be used as a complete integrated package along with Storage and valve components, completer kits, control panel and detection or alarm devices & accessories. NOVEC 1230 Gas Suppression System extinguishes fire in capabilities of 10 seconds or less. It works fast and effectively before any damage has been done to your valued assets. NOVEC 1230 Gas Suppression System acts by physically removing the heat energy from the flames and thus protects the occupied spaces. It is UL certified which means that it meets the internationally recognized Standards for Safety.
NOVEC 1230 Gas Suppression System has the following benefits:
- Ozone Depleting Potential (ODP) of zero.
- Global Warming Potential of One
- 5 days atmospheric lifetime
- No post-fire residues
- Electronically non-conductive
- SNAP (Significant New Alternatives Policy) List approved
- Safe to use in a wide range of occupied hazard areas
NOVEC 1230 Gas Suppression System finds its application in safeguarding lives, assets and reputations. It is used in telecommunication facilities, computer operations, art galleries, electronics & data processing units, petrochemical installations, shipboard, record & storage facilities, rare book libraries, control rooms and universities & museums.
Non magnetic Cylinder with clean agent is specially designed for MRI Rooms.
FM 200/Hfc227ea 25 Bar/42 Bar IndusTrial Fire Safety Solutio
Clean, Eco-Friendly, and Extremely Efficient
FM 200 also known as HFC227ea is a synthetic fire suppression gas that extinguishes the fire by removing the heat elements from the fire triangle of oxygen, fuel and heat. It is a waterless fire protection system found as an active compound and as a propellant in medical inhalers. This clean and environmentally friendly fire suppression system is electrically non-conducive. The FM 200 Gas Suppression system extinguishes the fire immediately within 10 seconds and is extremely safe for occupied spaces with the correct fire suppression design. The FM 200 Gas Suppression System has some components and their associated accessories. It is UL certified which means that is safe to use for humans and in occupied spaces.
Benefits of FM 200 Gas Suppression System:
- A small amount of FM 200 /Hfc227ea agent is enough to suppress a fire. Hence, a few cylinders mean less space for storage.
- FM 200 is a clean agent and can be used safely in occupied areas.
- FM 200 has minimal impact on the environment and does not deplete the stratospheric ozone.
- It extinguishes the fire in less than 10 seconds hence stopping the fire from causing significant damage.
- FM 200 system is designed to have simple refilling which in turn means less disruption to your business.
FM 200 Gas Suppression System is used in hundred thousands of applications worldwide like in pharmaceutical & medical facilities, universities & museums, marine systems, control rooms, telecommunication facilities, server room, data centers, UPS room, Battery room, historical archive storage, art galleries, record & storage facilities and electronics & data processing centers. It responds quickly at low concentrations and offers the greatest margin of safety for use in the protected area.
This system has been successfully implemented and widely accepted to protect large-room fires for:
- Huge data center
- Server room
- UPS room
- Battery room
- Hospitals
- MRI room, non-magnetic
Fire Alarms
Alarming the Alarms!
A fire alarm system is an integrated set of devices working in tandem to detect and warn people of an exceeded limit of smoke or fire. A fire alarm system effectively controls all the fire alarm modules in a building. A fire alarm system may consist of the following components:
- Fire alarm control panel: This hub monitors inputs and system integrity. It controls the output and finally relays the information.
- Primary power supply: This is in the form of 124 V or 240 V AC supply from the power company mains.
- Backup power supply: This usually consists of lead batteries and is used in case of main power system failure.
- Initiating devices: This activation stations can be manual or automatic. The manual initiating device examples are buttons, pull stations or the break glass station. The automatic initiating devices are heat, flame, CO or the smoke detectors.
- Notification appliances: Strobe lights, sirens, speakers, horns, flashing lights are all the notification appliances that warn the people of fire in their premises.
- Building safety interfaces: The things like ventilation systems and exit lighting are the interfaces that help people to get out of a building that is on fire.
The fire alarm system is set off automatically or manually by the initiating systems. The sensors detect the increased heat levels and that triggers an alarm through the notification appliances via the fire alarm control panel. The fire alarm system is used in houses, workplaces, schools, colleges, industrial units, hospitals, power generation units, marine units, factories, storage houses and banks.
